Pre-Hardened vs. Annealed Die Blocks: Which Saves More Machining Time
Ask three machinists whether Pre-Hardened vs. Annealed Die Blocks save more machining time, and you will probably hear three different answers. Each one can be right, because each is measuring something different.
If you count the hours the cutter spends in the steel annealed wins. The steel is softer so you can push harder. But a die block is not finished when roughing ends. It still has to go out for hardening, come back, be ground or EDM’d to size, and sometimes be corrected because it moved. Count all of that, and a pre-hardened block such as P20 or P20+Ni often reaches a finished tool sooner.
We have been supplying tool and die steels since 1957, and this is one of the oldest debates in any toolroom. Here is how we would think it through, using the hardness figures from our own product pages.
Pre-Hardened vs Annealed Die Blocks in One Minute
Annealed die blocks arrive soft. They cut quickly and go easy on tools, but they must be hardened and tempered after machining. H13 and D2 are the usual examples.
Pre-hardened die blocks arrive already hardened and tempered. They cut more slowly and need better tooling, but once machined, you are done: no furnace, no waiting. P20 and P20+Ni are the usual examples.
Heavy material removal or a high working hardness? Look at annealed. Moderate removal, tight tolerances and a deadline? Pre-hardened is usually the safer bet.
What Are Annealed Die Blocks?
Annealed die blocks are softened at the mill so they machine easily. On our datasheets, H13 is soft annealed to a maximum of 240 HB and HCHCR-D2 to a maximum of 250 HB. That is soft enough for fast roughing, drilling and tapping.
The catch is that annealed steel is not ready to work. After machining, it has to be hardened and tempered. H13 is hardened at roughly 1030 to 1060 °C and then tempered back to a working hardness, typically 44 to 52 HRC. D2 can be taken to 55 to 62 HRC. Then comes finishing.
What you gain: quick roughing, long tool life, and a working hardness that pre-hardened steel simply cannot reach.
What it costs you: an extra process (usually an outside heat treater), size change during hardening, and a small but real risk of distortion or cracking.
What Are Pre-Hardened Die Blocks?
Pre-hardened die blocks are hardened and tempered at the mill before they reach you. P20 is supplied at roughly 28 to 34 HRC, and P20+Ni at around 280 to 320 HB, with the nickel keeping hardness more even through thick sections. For tougher duty, there is a higher-hardness P20+Ni variant, HXM 24, at 360 to 400 BHN.
You machine the block to final dimensions and it goes into service. The hardness is fixed, so you cannot raise it, and these grades are not the right choice for very abrasive duty. Nitriding or flame hardening can add a tougher outer layer to the cavity face.
What you gain: no heat treatment, no hardening distortion and a shorter route to a mould.
What it costs you: faster tool wear while cutting, and a ceiling on how hard the finished tool can be.
Why Annealed Die Blocks Save Machining Time
On the machine softness feels like a gift. Lower cutting forces mean you can run feeds and take deeper cuts. The tools stay cooler and last longer so the operator changes inserts often. Drilling cooling channels or tapping ejector holes, which can be miserable in harder steel, becomes routine work.
It matters most on big blocks with a lot of steel to remove.If you are carving out a cavity or if you are carving out a large die profile, a small saving, on every cubic centimetre adds up to many hours. Many shops rough in the soft state, stress relieve, then harden and finish. For D2, our datasheet calls for stress relief after rough machining at roughly 600 to 650 °C.
The Machining Time Paradox: Material Removal Volume
Here is the paradox: annealed steel is faster to cut, but it is not always faster to finish. What decides it is how much steel you remove compared with the largely fixed time that heat treatment takes.
The penalty for cutting harder steel grows with volume. Remove a little and you barely notice; remove a lot and it hurts. Heat treatment is different. Hardening, tempering, transport, the wait for a furnace slot and the finishing afterwards take about the same time whether your cavity is shallow or deep.
Think of it as a break-even point. A shallow-cavity mould usually finishes faster in pre-hardened steel. A deep, heavily profiled die often finishes faster in annealed steel. We cannot give you one percentage that works for every shop, because it depends on your machine, your tooling and your heat treater. The best way to find out is to run a trial cut and track your cycle times.
When Pre-Hardened Blocks Save Time Instead
Pre-hardened wins when you count the whole job, not just the spindle.
No Heat Treatment in Your Schedule
Without hardening, the block does not go to a heat treater, so you do not wait for a furnace slot or for the block to come back. On prototype tools and urgent mould work, that gap alone can outweigh the extra cutting time. Research from Chalmers University on mould steels makes the same point: the pre-hardened condition has become popular because of its shorter lead times compared with roughing soft and hardening later.
Even Hardness Through Thick Blocks
On a mold base if the hardness is not even the cutting tool will act differently from the outside to the inside. This is why we usually suggest to people buying blocks to go with P20+Ni. The nickel, in this material helps make the hardness even all the way through.
Less Distortion, Less Rework
The block is already at working hardness, so there is no hardening distortion to chase afterwards. You can leave smaller finishing allowances and skip much of the grinding and EDM correction. Heavy machining can still leave behind stress in the metal. That’s why our P20 datasheet says to stabilize machined dies at about 460 to 500 °C just before doing the final machining.
Getting the Most Out of Pre-Hardened Steel
Use machines and holders use coated carbide tooling and use the cutting data from your tool supplier. Keep cuts consistent. Clear the chips well. Do not run parameters on it and hope for the best.
Machining Time: Pre-Hardened vs Annealed Die Blocks
Here is how the two compare side by side, using the grades we stock.
| Factor | Annealed (H13, D2) | Pre-Hardened (P20, P20+Ni) |
| Supplied hardness | H13 max 240 HB, D2 max 250 HB | P20 about 28 to 34 HRC, P20+Ni about 280 to 320 HB |
| Cutting speed and feed | Higher | Lower |
| Tool wear | Lower | Higher; carbide preferred |
| Roughing time on large removal | Shorter | Longer |
| Heat treatment after machining | Required | Usually not required |
| Distortion risk | During hardening | Low; only stress release |
| Overall lead time | Longer, includes heat treatment | Often shorter |
| Working hardness | H13 about 44 to 52 HRC, D2 55 to 62 HRC after treatment | Fixed at supplied hardness; surface can be nitrided |
| Typical use | Die casting, forging, extrusion, stamping dies | Injection moulds, mould bases, bolsters |
Figures are from the Virat Special Steels product pages. Confirm them against the mill test certificate for your lot.
What to Check Before You Order
Two blocks that have the same grade name can behave differently so don’t just look at the label. Check the hardness that is provided and how even it is, throughout the section. Look at the thickness. The shape you need. The shape you need could be flat, square or round. Also check the paperwork. If you are purchasing H13 for aluminum die casting ask about the ESR grade well.
Chemical composition, hardness range and standards are different for each grade and each supplier. Trust the datasheet and certificate, for the material you actually get.
Where Each Type Is Used Pre-Hardened vs Annealed Die Blocks
Annealed Die Blocks
Annealed grades go into tools that need high working hardness. H13 is commonly used for aluminium and zinc die casting, as well as for hot forging and extrusion dies. DB6 (DIN 1.2714) is often chosen for forging and hammer forging dies, where toughness under shock is more important than hot hardness. D2 is well suited to blanking, punching and stamping dies, as well as shear blades and slitters.
Pre-Hardened Die Blocks
Pre-hardened grades fit tools where machinability and speed matter more than extreme hardness. P20 and P20+Ni are used in injection mould cavities, cores, mould bases, bolsters, die holders and press cassettes for consumer goods and domestic appliance tooling and P20 tooling is common, in these applications. .
How to Choose Between Pre-Hardened vs. Annealed Die Blocks
If you are stuck, run through these questions:
- What hardness does the finished tool need? Above the pre-hardened range, annealed is your answer.
- How long will the tool run, and how abrasive is the material going through it?
- How much steel are you actually removing?
- How tight are the tolerances, and how complex is the shape?
- How soon do you need it?
- Do you have a heat treater you trust nearby?
Still not sure what to do? Send us the drawing and the length of the run you are expecting. We will help you figure it out.
Why Choose Virat Steels Pre-Hardened and Annealed Die Blocks
We started in 1957 as Dhingra Mill Store. Virat Special Steels now carries around 3,500 tons of stock across 35+ grades, in two yards: Ludhiana (Punjab) and Gurgaon (Haryana). That is why many orders can go straight off the shelf. For die blocks, it also means you can get both sides of this article from one supplier.
- Pre-Hardened vs. Annealed Die Blocksunder one roof.Hot work and cold work grades like H13, DB6 and D2, and plastic mould steels like P20 and P20+Ni.
- Mill-backed material. We stock steels from mills such as Swiss Steel Group, NLMK Verona, Lucchini RS and ThyssenKrupp.
- Technical help, not just a price. Our team advises on material choice, heat treatment and machining, so you pick the condition that saves you time.
- Paperwork you can show your customer. Mill test certificates and quality assurance reports come with every order, and our ISO and MSME certificates are on our downloads page.
- Quick quoting.Use the enquiry form, call +91-98140 21775, or message us on WhatsApp.
Questions Buyers Ask Before Ordering Die Blocks
Is P20 pre-hardened, or do I have to harden it after machining?
P20 is supplied pre-hardened at roughly 28 to 34 HRC, so you can machine it and put it into service right away. No hardening step is needed. If you want a tougher surface on the cavity, you can add it by nitriding.
Should I buy H13 annealed or pre-hardened for die casting?
H13 is normally supplied annealed. You machine it, harden and temper it, then finish. For specific applications we can supply pre-hardened H13, and our product page quotes 460 to 500 BHN. Tell us the application first.
Will pre-hardened steel really save me machining time over annealed?
It saves total time because you skip heat treatment, but the cutter works harder. If you are removing a lot of steel, annealed can be quicker at the machine. Look at the whole job, not just the cutting.
What is the difference between P20 and P20+Ni?
P20+Ni has added nickel. Nickel gives uniform hardness through thick sections. Nickel also gives a polish. It is the usual pick for big mould blocks and mirror finishes. P20 is the economical choice for small to medium blocks.
How thick can I get P20?
Our P20 page lists sections up to 255 mm thick. For larger blocks, talk to us. P20+Ni is often the better fit for large sections.
What hardness will I get if I harden H13 or D2 myself?
On our datasheets, H13 reaches about 55 HRC as quenched and D2 about 63 HRC. Both are then tempered, typically to 44 to 52 HRC for H13 and 55 to 62 HRC for D2. Your heat treater sets the exact cycle.
Can I machine pre-hardened steel with normal tooling?
You can, but carbide tooling and a rigid setup make life much easier. Reduce your speeds and feeds compared with annealed steel, and follow your tool maker’s advice.
Do I need to stress relieve a pre-hardened block?
For heavily machined dies, stabilise the block at roughly 460 to 500 °C just before finish machining, then air cool. Our P20 datasheet advises this, and it is cheap insurance on a big mould.
Can P20 or P20+Ni be nitrided?
Yes. Both respond well to nitriding, and P20+Ni can also be flame hardened to create a harder surface. Check the nitriding temperature with your heat treater so that the block does not become soft. .
Can pre-hardened steel be welded for mould repair?
Yes, with a matching filler and the right procedure. For P20, our page suggests a preheat of 200 to 300 °C and post-weld tempering. Ask us before you start on a critical repair.
H13 or DB6 for my forging die?
DB6, DIN 1.2714 standard is the preferred metal when you need a piece that can take a hard hit. DB6 works best for forging and hammer forging because toughness under shock matters most. H13 is the choice, for die casting and extrusion because heat resistance and thermal fatigue matter most.
Do you supply ESR H13?
Yes. ESR H13 is suggested for aluminum pressure die casting and other situations that involve temperature and high pressure. Let us know about your use and we will give you guidance.
Do you send test certificates with the steel?
Yes. We offer mill test certificates and quality assurance reports with each order. If your project requires anything let us know as soon, as possible.
Which sizes and shapes do you supply?
Flat bars, square bars and round bars, in the sizes that fit your requirement. Just let us know the dimensions and quantity that you need.
Where do you ship from, and how fast can you deliver?
We have stock, in Ludhiana and Gurgaon and I supply across India. Delivery time depends on grade, size and your location so give me the details and I will confirm .
How do I get a quote?
Send the grade, condition, size and quantity through our enquiry page, email info@viratsteels.com, or call +91-98140 21775.
So, Which Saves More Machining Time?
If you are counting spindle hours, annealed die blocks win, especially when there is a lot of steel to remove or you need a high final hardness. If you are counting days to a finished tool, Pre-Hardened vs. Annealed Die Blocks often win, because they skip heat treatment and avoid hardening distortion.
Not sure which suits your next job? Talk to the Virat Steels team. Send us the grade, size, condition and quantity through our enquiry page, call +91-98140 21775, or email info@viratsteels.com. We will help you compare Pre-Hardened vs. Annealed Die Blocks options and put a quote together.
Cut-to-Size Die Blocks: Machining Allowance Guide for DB6, H13, D2 & P20
Technical guide by Virat Special Steels · Die and tool steel stockists since 1957
Order a Cut-to-Size Die Blocks with too little allowance and it can’t be cleaned up after heat treatment, so it ends up as scrap. Order too much and you pay for steel, sawing and machine time that turns into chips.
This manual provides us with a summary of the allowance for machining based on the requirements of the various categories from the Indian forging, die-casting, and toolroom industries including DB6 (DIN 1.2714), H13, H11, D2, D3, and P20.
Machining Allowance for Cut-to-Size Die Blocks
Plan these ranges per side (per face), then confirm with your supplier:
| Delivery condition | Allowance per side | What it has to cover |
| Black (hot-rolled or forged) | 3–6 mm for most sizes; more on wide sections | Scale, seams, decarburized skin, bow |
| Saw-cut and rough-milled | 1–2 mm | Remaining geometry error, semi-finishing |
| Six-side milled | 0.2–0.4 mm | Final sizing; standard programmes ship +0.4 to +0.8 mm over nominal overall |
| Precision ground with allowance | 0.15–0.3 mm | Final sizing only |
If hardening is going to be done after machining the piece, allow for at least 0.15% of each dimension on each side for the final finishing of the piece. For instance, a 200 mm face would require about 0.3 mm to be kept.
These figures are based on available data from the mills and actual shop practice; they should not be considered standard values. The actual numbers may depend on the type of alloy, the shape of the section and the method you use. Therefore, make sure to send an engineering drawing before you finish up.
What Is Machining Allowance on a Die Block?
The machining allowance refers to the additional material requested to have the workpiece in its finished form. This is often defined by a number for each side, such as 3 mm per side for a 6 mm allowance in total. With cut-to-size die blocks, you would incorporate this allowance in your order specifications and make sure to mention it on the order.
Breakdown of Machining Allowance Layers
Total allowance is a stack of four layers, and each one exists for a reason.
| Layer | What it covers | Planning figure per side |
| 1. Surface | Scale, seams, laps and the decarburized skin left by hot working | 1.6% of the dimension, usually not under 2 mm |
| 2. Geometry | Bow, camber, out-of-flat and cutting tolerance | 0.3–0.5 mm |
| 3. Heat treatment | Hardening movement, residual scale or decarburization | 0.15% of the dimension, minimum about 0.3 mm |
| 4. Finishing | EDM recast removal, polishing | Small; set by the finishing process |
Layer 1: surface. Hot rolling and forging leave scale, seams and a skin where carbon has burned out. That soft skin won’t harden properly, so it must go. The AISI benchmark for hot-rolled flats and squares is removal of at least 1.6% of the dimension per side (2.4% for resulfurized steel). It was written for carbon and alloy bars, so treat it as a floor for tool steel. Decarburization depth is measured to ASTM E1077 or ISO 3887.
Layer 2: geometry. No bar is perfectly straight or flat, and long pieces bow more. Cutting adds tolerance, and length is the loosest dimension: +3/+8 mm on Uddeholm’s saw-cut stock, up to +35 mm in some precision flat programmes. Never rely on sawn length for a fit.
Layer 3: heat treatment. The sound workflow is rough machine, stress relieve, semi-finish, harden, grind. Uddeholm recommends 650°C for two hours after roughing H13; Virat’s DB6 guidance is 600–650°C. The Böhler-Uddeholm D2 data sheet sets a minimum of 0.15% per side, but only with stress relief, and Uddeholm’s oil-hardening Arne steel lists 0.25%. Movement can be small: on a 100 × 100 × 25 mm H13 sample, thickness changes 0 to +0.05% after air hardening and up to +0.30% after oil hardening. Scale and decarburization from hardening must also be ground off, so the allowance is never just the movement figure.
Layer 4: finishing. Wire EDM leaves a recast layer. Uddeholm advises removing it by grinding or stoning, then re-tempering about 25°C below the previous tempering temperature. Polishing needs little stock.
Formula and Worked Example
Per side: cleanup (the greater of 2 mm or 1.6% of the dimension) + geometry buffer (0.5 mm) + grinding stock (0.15% of the dimension, minimum 0.3 mm). Order size = finished size + 2 × that total.
For instance, a D2 block, which has a final measurement of 250 × 150 × 50 mm owing to the black flat finish, requires a thickness of 4.9, 3.2 and 2.8 mm on each side. This means that one should order something in the order of 260 × 157 × 56 mm with the understanding that this is merely an estimate rather than a guarantee.
Seven mistakes that cost money
- Writing “+5 mm” without saying per side or total.
- Using one allowance for every grade and condition.
- Ignoring bow on long flats.
- Skipping stress relief between roughing and finishing.
- Accepting a gas-cut block to save a few rupees.
- Expecting ESR to shrink the allowance. ESR cleans the inside of the steel. The surface still carries scale and decarb.
- Hoping allowance will fix internal defects. It won’t. For critical blocks, ask for ultrasonic testing.
What to send with your enquiry
- Grade and drawing, with finished size (L × W × T)
- Process route: use as supplied, or harden after machining
- Heat-treatment method: vacuum or atmosphere furnace
- Supply condition wanted: black, milled or ground
- Cutting method and tolerance (saw cut, plus-only or plus-minus)
- Documents needed: MTC, UT, spectro check
- Quantity and delivery location
Specific Scenarios and Add-Ons
Pre-hardened die blocks (DB6, H13, P20). Virat supplies DB6 annealed or hardened and tempered, typically at 38–44 HRC. If you machine the block as supplied, Layer 3 disappears. Keep Layers 1, 2 and 4, and confirm the condition at order stage.
Hardening after machining (D2, D3, soft H13). Use all four layers. Machine soft, stress relieve, harden, then grind.
Wire EDM. Blocks for eroding are often bought hardened and ground, sometimes with start holes. Allow for recast removal and agree finishing stock with your EDM shop.
Flame or plasma-cut blanks. Avoid them for alloy tool steel. Thermal cutting leaves a hardened heat-affected zone and cracking risk, and needs far more stock. Band-sawing is the safer route.
Large forged blocks. Allowance grows with size, so never reuse a 100 mm figure on a 400 mm block. For heavy die blocks, ask for ultrasonic testing. Virat supplies DB6 die blocks with extra forging reduction and double tempering for better UT quality.
Nitriding. Nitrided cases are shallow (about 0.12–0.20 mm in Uddeholm’s H13 examples), so finish the block first and treat nitriding as a surface step, not an allowance layer.
Add-ons to request on your enquiry:
- Bandsaw cut-to-size and surface machining
- Annealed or hardened-and-tempered supply; ESR or non-ESR
- Ultrasonic testing
- Mill Test Certificate (EN 10204 3.1 where applicable), spectro and hardness reports
- Ground reference faces with squareness and parallelism limits
- Batch-wise traceability
Common Material Grades for Cut-to-Size Die Blocks
Allowance logic changes with the grade and its supply condition:
| Grade (AISI / DIN) | Typical use | Allowance note |
| DB6 / 1.2714 (L6) | Hammer and press forging dies | Often supplied hardened and tempered, so no heat-treatment layer |
| H13 / 1.2344 | Die casting, extrusion, hot forging | Air or vacuum hardening keeps movement small; stress relief still applies |
| H11 / 1.2343 | Forging and aluminium extrusion dies | Plan like H13 |
| D2 (HCHCr) / 1.2379 | Blanking and forming dies, punches | Air hardening; keep at least 0.15% per side with stress relief |
| D3 (HCHCr) / 1.2080 | High-abrasion, long-run tooling | Oil hardening; leave more grinding stock than D2 |
| P20 / 1.2311 | Plastic mould blocks | Usually pre-hardened; no heat-treatment layer |
| P20+Ni / 1.2738 | Large mould blocks | Better through-hardening in thick sections |
Sourcing and Customization Options
Virat Special Steels has nearly 3,500 tons in over 35 grades available at its yards in Ludhiana and Gurugram, resulting in large amounts of cut-to-size die blocks shipped out from stock. The billets originate from mills such as Swiss Steel, NLMK Verona, Lucchini and ThyssenKrupp. Blocks reach you in four conditions, each trading price for convenience:
- Saw-cut black block: lowest cost per kg, most allowance to remove.
- Rough-milled: surface layer gone, flatter.
- Six-side milled: close to size, less machining time. Check the stock left if you will harden.
- Hardened and ground: ready for EDM or fitting, with no allowance for further heat treatment.
Include these on your enquiry:
- Grade and delivery condition
- Finished size and order size, stating per side or overall
- Faces to be ground, with tolerances
- Hardening plan and target hardness
- Testing and certificates needed
- Quantity and delivery date
Contact VIRAT for Drawing-Based Sizing and a Quotation
Let us know your engineering drawing, steel grade, dimensions after machining (L x W x T), desired supply condition, volume, and destination point for supply by Virat Special Steels. Our experts will assist you in estimating machining allowance and provide appropriate die blocks as per your needs.
You may get in touch with us at +91-98140 21775 or write to us at info@viratsteels.com to request for a quotation. We manufacture DB6, H13, H11, D2, D3, and P20 tool and die steels from our Gurugram and Ludhiana plants, supplied across India as per availability.
Frequently Asked Questions
1. How much machining allowance should I leave on a die block? Plan 3–6 mm per side on black stock, 1–2 mm on rough-milled and 0.2–0.4 mm on six-side milled blocks, plus grinding stock if you will harden afterwards.
2. Is machining allowance per side or total? Normally per side. A 3 mm allowance adds 6 mm to each dimension, so always state “per side” or “overall” on your enquiry.
3. How much allowance should I keep for grinding after heat treatment? At least 0.15% of the dimension per side for D2 after stress relief. Oil-hardening grades need more; Uddeholm lists 0.25% for its O1-type Arne steel.
4. Do pre-hardened DB6 (DIN 1.2714) die blocks need heat-treatment allowance? Not if you machine them as supplied, typically 38–44 HRC. Keep the surface, geometry and finishing allowances only.
5. What do black, rough-milled and six-side milled mean? Black keeps the as-forged or as-rolled skin. Rough-milled has the skin removed with stock left. Six-side milled is square and parallel, close to final size, so you can start machining straight away.
6. What do “hot die steel”, “HCHCr”, “OHNS” and “die block” mean? Hot die steel is hot-work steel such as H13, H11 and DB6. HCHCr is high-carbon, high-chromium cold-work steel (D2 and D3). OHNS is oil-hardening non-shrinking steel, usually O1. A die block is a large forged or rolled block used for forging and casting dies.
7. Can I flame-cut or plasma-cut a die block? Avoid it for alloy tool steel. These processes will create a hardened heat-affected area, with the possibility of fracture and wasted material. Instead, consider using a band saw.
8. How much stock should I leave for wire EDM? Enough to remove the recast layer by grinding or stoning, followed by re-tempering about 25°C below the last tempering temperature. Agree exact stock with your EDM shop.
9. What tolerance can I expect on cut length? Length is the loosest dimension. Published saw-cut tolerances run from +3/+8 mm to +35 mm, so ask your supplier for its tolerance and never rely on sawn length for a fit.
10. Db6 or H13 for forging die blocks? The typical material for hammering and press dies is DB6 (DIN 1.2714), while H13 (DIN 1.2344) is the preferred alloy for hot-working conditions like die casting, extrusion, and hot forging. This depends on temperature, impact loads, die configuration, and service life.
11. Does D2 or O1 (OHNS) need more allowance? O1, an oil-hardening grade, needs more grinding stock than air-hardening D2. “Non-shrinking” does not mean no movement.
12. Can I buy a small cut piece instead of a full bar? Yes. Virat Special Steels can provide steel that is cut to size depending on the grade, dimensions and availability of stock. Please inform us of your desired dimensions and quantities.
13. Is cut-to-size priced per kg or per piece? Most manufacturers charge according to the overall weight including the costs of cutting and machining. The extra allowance will be reflected in the weight, too, so you should size it accurately and ask them for your cutting estimate.
14. How can I check I received the grade I ordered? Ensure that the heat number on the material marking is the same as stated in the Mill Test Certificate (MTC). Another way would be to ask for an OES analysis to prove the steel grade. Spark testing cannot be considered a reliable way of verifying the alloy tool steel grade.
15. Can I get MTC and ultrasonic testing on cut-to-size blocks? Yes, request them at order stage. Virat supplies MTC (EN 10204 3.1 where applicable), UT-tested material and spectro verification, subject to grade and product.
16. How fast can I get a quotation and delivery? To receive a quotation from Virat Special Steels, share your steel grade, drawing or size, quantity, and the place where the delivery will take place. The lead time varies from time to time, based on availability of material, any cutting/machining work, testing, and transport.
17. How do I calculate die block weight? Length × width × thickness in mm ÷ 1,000,000 × 7.85 gives kg, using a typical tool steel density of 7.85 g/cm³. A 250 × 150 × 50 mm block weighs about 14.7 kg.
18. Where can I buy cut-to-size die blocks in India? Virat Special Steels supplies DB6, H13, H11, D2, D3 and P20 die blocks from ready stock at Ludhiana and Gurugram, with PAN India delivery, subject to grade and size.
